40
EN
3
2
1
A
Fig. 31
4.6 REAR SHOCK ABSORBER ADJUSTMENT
• The rear shock absorbers can be adjusted on the preloading
of the spring, through which it is possible to adapt the scooter’s
behaviour according to the load, driving conditions and type of
road.
• The adjustment is carried out using the special spanner fitted
to the ring nut (A – fig. 31). If you turn it clockwise, the spring’s
force will be increased.
Note: there are three adjustment positions:
1) ‘STD’ – rider only – minimum load – uneven roads
2) ‘Medium’ – with passenger; variable load – various road
conditions
3) ‘Hard’ – with passenger – maximum loads
Adjust both shock absorbers according to the same ad-
justment index. An unbalanced adjustment may com-
promise the vehicle’s stability.
