38
EN
A
B
S
Fig. 28
Fig. 29
MIN
S
4.4 FRONT/REAR BRAKE OIL
Check every 30 days
• This (visual) check shall be carried out by means of the sight
glasses (S): A – Fig. 28 (front brake) and B – Fig. 29 (rear
brake), when the scooter is on a level ground and perfectly
upright.
• The level is correct when the oil is 3 mm above the bottom
mark of the sight glass.
• Topping up shall be carried out by removing the covers (A-B),
after unloosening the two fastening screws. We advise you to
use Q8 BRAKE FLUID DOT 4 oil.
Hydraulic oil is corrosive and can cause damages and
injuries. Do not mix different types of oil. Check the perfect
seal of the gaskets.
Replace every 2 years or 12,000 km (7440 mi)
• If the fluid contains dirt or water, it must be replaced.
• A spongy feeling in the brake lever can indicate the presence
of air in the circuit. Have the vehicle checked by an Authorised
Malaguti Service Centre.
Note: to ensure long life and efficiency for your scooter, we advise
you to have these operations performed by an Authorised
Malaguti Service Centre.
