Malaguti PHANTOM MAX 250 - 2 Getting to Know Your Vehicle; 2.1 Technical Data

11
EN
GETTING TO KNOW YOUR VEHICLE
2
2.1 TECHNICAL DATA
MALAGUTI Spa reserves the right to modify the technical data at any time
without notice.
NOTE: the data between brackets refer to the 125 cc
version, when different from the 250 cc version.
Size
Wheel base ------------------------------------------------- 1.410 m (1.400 m)
Max. length --------------------------------------------------------------- 1.980 m
Max. width ---------------------------------------------------------------- 0.760 m
Max. height --------------------------------------------------------------- 1.280 m
Kerb weight --------------------------------------------------- 143 kg (139 Kg)
Max. recommended load:
rider, passenger and luggage ---------------------------------------- 170 Kg
Capacity
Engine oil --------------------------------------------------- 1000 cc (1400 cc)
Transmission oil ---------------------------------------------- 250 cc (140 cc)
Fuel tank with low fuel level ---------------------------------------------- 9.5 l
Engine: 4-stroke, 4-valve (2-valve)
Type ------------------------------------ PIAGGIO M361M (MINARELLI 3M5)
Cylinders --------------------------------------------------------------------------- 1
Bore/stroke mm ------------------------------------- Ø 72 x 60 (53,7 x 54,8)
Capacity ---------------------------------------------------- 244 cm³ (124 cm³)
Compression ratio ------------------------------------ 11.0 : 0.5 (11.0 : 1.0)
Cooling ------------------------------------------------------------------------- liquid
Starting system ------------------------------------------------- electric starter
Greasing system -------------------------------------------------- oil-bath type
Ignition system ---------------------------------- electronic CDI (electronic)
Spark plug
Type --- CHAMPION RG4HC - NGK CR7EB - NGK CR8EB (NGK - CR8E)
Electrode gap ----------------------------------------------------- 0.6 ÷ 0.7 mm
Transmission
Type: automatic speed variator with single-speed V- belt.
Main reduction system: gear type
Clutch: dry, centrifugal and automatic.
Fuel system
Carburettor make/type: WALBRO - KEI HIN - MIKUNI (TEIKEI - 5XL)
Automatic starter.
Fuel: unleaded petrol.
Brakes
Front disk brake ø 220 with hydraulic transmission and hydraulic two-
piston caliper.
Rear disk brake ø 220 with hydraulic transmission and hydraulic caliper.
Frame
Steel tube single beam, split at the footrest.
Suspensions
Front: hydraulically controlled fork with two Ø 33 mm rods. Stroke 90 mm.
Rear: 2 hydraulic shock absorbers with adjustable pre-loading spring.
Stroke 82 mm (88 mm).
Electric equipment 12V
Battery type: 12V 12Ah (12V 9Ah)
Front headlight with low beam, high beam, parking light.
Rear parking light with built-in stop light.
Horn: 12V.
Front and rear direction indicators.
Number plate light.
