20
EN
Fig. 16
4
3
1
2
5
Fig. 17
C
B
A
2.8 HANDLEBAR CONTROLS
Right handlebar
1) Front brake oil tank
2) Front brake lever
3) MODE button: selects the various functions of the digital dashboard
4) Twist grip throttle control
5) Counterweight
A ) Electric starter button
B) Light switch
right = OFF
centre = parking, dashboard and number plate lights
left = low/high beam
C) Emergency switch, engine stop
Position – Engine start.
Position – Engine stop.
