8
i
EN
T
1
A
Fig. 4
B
A
Fig. 6b
Fig. 6a
1.5 COOLANT TANK
To access the engine coolant tank, lift the cover (1 – Fig. 6a), by loosening
the screw (A - fig. 6a). See Section 5.5 (page 44) for information about
topping up.
Use the coolant prescribed in this Manual - or one having
the same characteristics - for any topping up.
Do not fill up with water, except in emergency situations.
Never unscrew the tank cap (T - Fig. 6b) when the engine
is warm so as to avoid burnings.
1.4 FUEL TANK
To gain access to the fuel tank, proceed as follows:
• Place the scooter on the centre stand.
• Remove the ignition key from the switch.
• Open the door (A - Fig.4) with the ignition key.
• Unscrew the cap (B - Fig.4) and fill the tank.
• Firmly screw the cap back onto the tank (B - fig. 4).
• After refuelling, check if there are any traces of petrol on the scooter. If
so, immediately clean the surface, in order to avoid any damage.
• The quantity of fuel, as well as a low fuel level, is displayed on the
dashboard by means of the l.h. instrument (see chap. 2.6).
• Use only UNLEADED PETROL.
Fuel is extremely inflammable. Avoid approaching the tank
filler with lighted cigarettes or naked flames (i.e. matches).
This also applies to refuelling: fire hazard!
FUEL TANK litres
TOTAL TANK CAPACITY 9.5
RESERVE 3
