Man D2862 LE221 - Common Rail System Component Removal and Installation

420 pages

To Next Page

To Previous Page

COMMONRAILSYSTEM

[30] Magneticpick-uptool

•Removingtherailconnection

80.99639-0009

[31]

Specialspanner,size17

•Detachingandattachingthehigh-pressurelines

inconjunctionwith:

•Angleextension[15]

80.99603-0309

[32] Angleextension

•Detachingandattachingthehigh-pressurelines

inconjunctionwith:

•Specialspanner,size17[14]

08.06139-9025

[33] Endplug

•Pluggingthehigh-pressurelines

81.96002-0521

[34] ProtectivesleeveZ14x15

•Pluggingthehigh-pressurelineconnections

81.96002-0512

AE63stedition119
