Removing,installingtheautomaticbelttensioner
Additionaljobs
–Removing,installingthecoolingsystem,see55
–Removing,installingtheramfan,see61
–Removing,installingthefanV-belt,see85
–Removing,installingthepoly-V-belt,see93
(1)Automaticbelttensioner
Technicaldata
Mountingbolt.......................................................M10x70-10.9......................................................47Nm
Importantinformation
WARNING
Componentdamageduetoincorrectlytightenedscrew/boltconnections
•Ifimpactwrenchesareused,thesemayonlybeusedforpretighteningtomax.50%ofthe
speciedtighteningtorque
•Finaltighteningmustalwaysbeperformedmanuallyusingatorquewrench
