Man D2862 LE221 - Turbocharger; Removing, Installing the Turbocharger

TURBOCHARGING
TURBOCHARGER
Removing,installingtheturbocharger
Additionaljobs
–Removing,installingtheairlter,see191
(1)Intakemanifold
(2)Turbocharger,right
(3)Turbocharger,left
(4)Intakemanifold
Technicaldata
Mountingnuts,turbocharger..................................M10...................................................................60Nm
Clamp............................................................................................................................................15Nm
T-pinclamp....................................................................................................................................15Nm
Serviceproducts
Engineoil..................................seeMaintenanceRecommendationsandRecommendedServiceProducts
Importantinformation
WARNING
Componentdamageduetoincorrectlytightenedscrew/boltconnections
•Ifimpactwrenchesareused,thesemayonlybeusedforpretighteningtomax.50%ofthe
speciedtighteningtorque
•Finaltighteningmustalwaysbeperformedmanuallyusingatorquewrench
Note
Therightturbochargerisremovedandinstalledinexactlythesameway
