Man D2862 LE221 - Oil Sump; Removing, Installing the Oil Sump

ENGINELUBRICATION
OILSUMP
Removing,installingtheoilsump
Additionaljobs
–Drainingandtoppinguptheengineoil,seeOperator'sManual
(1)Fusehousing
(2)Oilsump
(3)Oilreturnline
Technicaldata
Oildrainplug........................................................M26x1.5............................................................80Nm
Importantinformation
WARNING
Componentdamagecausedbycontamination
•Cleancomponentsandsealingsurfacesbeforeassemblyusingsuitablemeans
•Protectthecleanedsurfacestopreventthemgettingdirtyagain
WARNING
Componentdamageduetoincorrectlytightenedscrew/boltconnections
•Ifimpactwrenchesareused,thesemayonlybeusedforpretighteningtomax.50%ofthe
speciedtighteningtorque
•Finaltighteningmustalwaysbeperformedmanuallyusingatorquewrench
