ADD-ONUNITS
STARTER
Removing,installingthestarter
Additionaljobs
–Disconnectingandconnectingthebattery,seeOperator'sManual
(1)Starter(2)Mountingbolt
Technicaldata
Mountingnut,terminal30......................................M12...................................................................25Nm
Mountingnut,terminal31......................................M12...................................................................25Nm
Mountingnut,terminal50......................................M6.....................................................................4Nm
Mountingnut,terminal85......................................M6.....................................................................4Nm
Numberofteethonstarterpinion..........................................................................................................11
Starterpower..........................................................................................................................24V/7KW
Importantinformation
WARNING
Componentdamageduetoincorrectlytightenedscrew/boltconnections
•Ifimpactwrenchesareused,thesemayonlybeusedforpretighteningtomax.50%ofthe
speciedtighteningtorque
•Finaltighteningmustalwaysbeperformedmanuallyusingatorquewrench
AE63stedition81
