Man D2862 LE221 - Removing, Installing the Engine Oil Pressure Sensor

To Next Page

To Previous Page

ENGINEELECTRICS

Removing,installingtheengineoilpressuresensor

(1)Oilpressuresensor

Technicaldata

Oilpressuresensor..............................................M18x1.5............................................................47Nm

Serviceproducts

Engineoil..................................seeMaintenanceRecommendationsandRecommendedServiceProducts

Importantinformation

WARNING

Componentdamageduetoincorrectlytightenedscrew/boltconnections

•Ifimpactwrenchesareused,thesemayonlybeusedforpretighteningtomax.50%ofthe

speciedtighteningtorque

•Finaltighteningmustalwaysbeperformedmanuallyusingatorquewrench

WARNING

Restrictedoperationduetoincorrectentriesinthefaultmemory

•Beforeremovingswitchesorsensors,readoutanddocumentthefaultmemory

•AlwaysinstallswitchesandsensorswithnewO-ringsorsealingrings

•Afterinstallingswitchesorsensors,readoutthefaultmemoryand,ifnecessary,deleteit

AE63stedition39
