Man D2862 LE221 User Manual

CYLINDERHEAD
Checkingandsettingthevalveclearance
Additionaljobs
–Removing,installingthecylinderheadcover,see213
(1)Adjustingscrew,exhaustvalve
(2)Adjustingscrew,intakevalve
(3)Valvebridge,intakevalve
(4)Valvebridge,exhaustvalve
Technicaldata
Intakevalveclearance................................................................................................................0.50mm
Exhaustvalveclearance.............................................................................................................0.80mm
Rockerarmadjustingscrewlocknut................................................................................................45Nm
Serviceproducts
WhiteTassemblypaste.....................................................................................................09.16012-0122
Importantinformation
WARNING
Enginedamagecausedbyincorrectlysetvalves
•Donotadjustthevalvesunlesstheengineiscold
238AE63stedition
