Man D2862 LE221 - Hand Pump; Removing, Installing the Hand Pump

COMMONRAILSYSTEM
HANDPUMP
Removing,installingthehandpump
(1)Handpump(2)Handpumpfuelline
Importantinformation
WARNING
Residualfuelmayrunoutduringremoval.Dangerofenvironmentalpollution.
•Useasuitablefuelcollectingcontainer
WARNING
Componentdamageduetoincorrectlytightenedscrew/boltconnections
•Ifimpactwrenchesareused,thesemayonlybeusedforpretighteningtomax.50%ofthe
speciedtighteningtorque
•Finaltighteningmustalwaysbeperformedmanuallyusingatorquewrench
Note
Inordertoensurethatthecorrectprotectivesleeveisused,thedesignation(e.g.Z14x15)is
imprintedintheprotectivesleeve.Thisisintegratedinthespecialtooldesignation(e.g.protective
sleeve,high-pressurelineconnectionZ14x15).
Note
Acheckvalveisintegratedinthehandpumptopreventthefuelfromowingback.
