COMMONRAILSYSTEM

Specialtools

[58]

Endplug(GPN330L18)

•Pluggingthefuellines

81.96002-0556

[59] ProtectivesleeveZ28x20

•Pluggingtheconnectiononthecollector

81.96002-0514
