CYLINDERHEAD
Assemblingthespecialtool
Note
RetainingwasherandHolder[91]have
left-handthreads.
PositiontheHolder[90](5)andHolder[91](3)on
Valve-springcompressor[89](1)andthenscrew
onbyturningthethreadedspindle(4)
Screwontheretainingwashers(2)and(6)
Positionthelever(8)ontheValve-spring
compressor[89](1)andsecureusingthe
mountingbolt(7)
Attachingthevalve-springcompressor
WARNING
Injectordamage
Thespringcompressormustnotcome
intocontactwiththeinjector
ScrewintheAdapter[86](4)
ScrewtheAssemblydevice[87](3)into
Adapter[86](4)
PositiontheHolder[90](5)andHolder[91](6)on
thespringcapandtensionbyturningthethreaded
spindle(7)
HooktheValve-springcompressor[89](2)inthe
Assemblydevice[87](3)
PlacetheExtension[88](1)ontoValve-spring
compressor[89](2)
Installingthevalvecotters
CAUTION
Riskofinjuryduetospringingbackof
thevalvesprings
EnsurethattheHolder[90]and
Holder[91]areseatedcorrectlyon
thespringcap
Donotinsertthevalvecottersintothe
valvespringwithyourbarehands
Pressthespringcap(4)downfullywith
Valve-springcompressor[89](3)and
Extension[88](2)
Insertthevalvecotters(1)
CarefullyunfastentheValve-spring
compressor[89](3)
Checkthevalvecotters(1)forcorrectseating,
repeattheprocedureasnecessary
Detachingtheenginebarringgear
RemovetheEnginebarringgear[84](1)fromthe
ywheelhousing
AttachtheTDCmarkingplate
Attachthecapwithnewsealontheywheel
housing
AE63stedition237
