CYLINDERHEAD
Installingthevalvestemseals
Installingthevalvestemseals
Note
Mountthegreenvalvestemsealsonthe
intakesideandthebrownvalvestem
sealsontheexhaustside
•ThinlyapplycleanengineoiltoMANStandard
3277ontheAssemblysleeve[94](4)andvalve
stemseal(3)
•PushtheAssemblysleeve[94](4)overthevalve
stem(5)
•Insertthevalvestemseal(3)intotheAssembly
device[93](2)andclamp
•PushtheAssemblydevice[93](2)overthe
Assemblysleeve[94](4)
•Knockthevalvestemseal(3)ontothevalvestem
(5)usingimpactweight(1)
•RemovetheAssemblydevice[93](2)andthe
Assemblysleeve[94](4)
Installingthevalvesprings
•Fitthewasher,valvespring(2)andspringcap(1)
overthevalvestem
•Repeatthesameprocedureforallthevalves
