ADD-ONUNITS
Removingthepoly-V-belt
Detachingthepoly-V-belt
CAUTION
Thepoly-V-belttensionerisunder
springtension
•Holdthepoly-V-belttensionersteady
topreventitfromspringingback
unintentionally
•Turnthepoly-V-belttensioner(1)clockwiseasfar
asthestopandholdit
•Removethepoly-V-belt(2)
•Carefullyrelievethepoly-V-belttensioner(1)
Installingthepoly-V-belt
Attachingthepoly-V-belt
CAUTION
Thepoly-V-belttensionerisunder
springtension
•Holdthepoly-V-belttensionersteady
topreventitfromspringingback
unintentionally
•Turnthepoly-V-belttensioner(1)clockwiseasfar
asthestopandholdit
•Fitthepoly-V-belt(2)
•Carefullyrelievethepoly-V-belttensioner(1)
