COMMONRAILSYSTEM
Detachingthecollector
•Marktheinstallationpositionofthecollector(2)
•Unscrewthemountingnuts(1)andpulloutthe
mountingbolts(3)
•Removethecollector(2)
Detachingtheholder
•Unscrewthemountingbolts(2)
•Removetheholder(1)withwashers(3)
Installingthefuellines
Attachingtheholder
•Positiontheholder(1)withwashers(3)
•Screwinandtightenthemountingbolts(2)
Mountingthecollector
•Positionthecollector(2)asmarked
•Insertthemountingbolts(3)
•Screwonandtightenthemountingnuts(1)
Attachingtheholder
•Positiontheholder(2)onthedistributor(1)
•Screwinandtightenthemountingbolts(3)
AE63stedition149
