Man D2862 LE221 - Page 208

INTAKE/EXHAUSTSYSTEM
Removingexhaustpipes
Detachingthecoverplate
•Marktheinstallationpositionofthemountingbolts
(1),(2),(3)and(5)
•Unscrewthemountingbolts(1),(2),(3)and(5)
andremovewithwashers
•Removethecoverplate(4)
Detachingthecoverplate
•Unscrewthemountingbolts(2)and(4)and
removewithwashers
•Removetheheatshield(1)
•Repeattheprocedureforcoverplate(3)
Detachingthecoverplateholder
•Unscrewthemountingbolts(2)andremovewith
washers
•Removetheholder(1)
•Repeatthesameprocedureforotherholders
Detachingthecoverplateholder
•Unscrewthemountingbolts(2)andremovewith
washers
•Removetheholder(1)
206AE63stedition
