CRANKSHAFTOILSEALS
Removingthefrontradialshaftseal
WARNING
Dangerofcomponentdamageonthe
cover
•EnsurethattheExtractorhook[110]
doesnothookinbehindthecover
•Extracttheradialshaftseal(1)usingImpact
extractor[109](3)andExtractorhook[110](2)
Installingthefrontradialshaftseal
•AssemblethePressingplate[114](3)withthe
Plug-onhandle[112](1)andWasher[113](2)
•Puttheclosedsideoftheradialshaftseal(4)onto
thespecialtool
•ScrewintheAligningtool[111](5)
•PushthespecialtoolontotheAligningtool[111]
(5)
•Pressintheradialshaftseal(4)asfarasthestop
usingthespecialtool
•Removethespecialtool
AE63stedition299
