CRANKSHAFTOILSEALS

[121] Press-inbush

•Installingtheradialshaftsealinconjunctionwith:

•Plug-onhandle[118]

•Washer[119]

•Guideplate[120]

•Aligningtool[122]

80.99604-0340

[122] Aligningtool

•Removing,installingtheywheel

•Installingtheradialshaftsealinconjunctionwith:

•Plug-onhandle[118]

•Washer[119]

•Guideplate[120]

•Press-inbush[121]

•Extractingthecrankshaftgearandradialshaft

sealinconjunctionwith:

•Impactextractor[116]

•Extractordevice[117]

80.99617-0220

302AE63stedition
