Man D2862 LE221 - Page 70

COOLINGSYSTEM
Attachingtheleftventline
•Positiontheringconnector(2)withnewsealing
rings(3)asmarked
•Screwinandtightenthehollowscrew(1)
Attachingtherightventline
•Screwinthehollowscrewconnector(1)witha
newsealingring(3)andtighten
•ScrewontheWDconnectingpiece(2)asmarked
andtighten
Attachingthecoolantline
•Positionthecoolantlinewithouttension
•Screwonandtightenunionnuts(1)and(3)
•Attachholdingclips(2)
68AE63stedition
