1312
2.7.3 Balance Adjustment of the Panning Axis
a. Tighten the pan axis positioning lock ①, loosen the pan axis positioning lock
②, keep the handle part of the Gimbal parallel to the ground and the vertical arm
parallel to the ground, and observe the camera rotation after the releasing.
b. Loosen the vertical arm lock screw ③, slide the vertical arm ④ to balance the
camera position.
c. Tighten the vertical arm lock screw ③ to rotate the pan axis to any angle, if it
stays stable, it means balanced.
2.8 Power ON/OFF
⚠
Before powering on the Gimbal, need to
unlock all the axis positioning lock.
Long press the power button, release it when
the display shows
Power
button
2.9 Download the Manfrotto Gimbal app.
Download Manfrotto Gimbal app.
