TRANSMISSION
22
20
647534EN
20 - 15/01/2017
TRANSMISSION
20.1 TRANSMISSION CHARACTERISTICS AND SPECIFICATIONS
20.1.1 PERMITTED MOVEMENTS
WORKING mode TRANSPORTmode
BASE BASKET BASE BASKET
Normal Tilt Overload Normal Tilt Overload Normal Tilt Overload Normal Tilt Overload
Travelling √ √ √
Steering
√
√
√
20.2 TRANSMISSION LOCATIONS
20.2.1 TRANSMISSION OVERVIEW
Accelerator valve
Brake unit
Steering
cylinder
Frame
function
block
Hydrostatic
pump
Front left-hand wheel motor
Rear left-hand wheel motor
Rear right-hand wheel motor
Front right-hand wheel motor
