Manitou MAN'GO 12 Repair Manual

25
TRANSMISSION
20
647534EN
20 - 15/01/2017
20.3 TRANSMISSION CONTROLS AND ADJUSTMENTS
20.3.1 CONNECTION OF WHEEL MOTOR HOSES
Brake hose (1, 020 - 17).
Drain hose (2, 020 - 17).
Travel hoses (3 , 020 - 17).
20.3.2 TRANSMISSION BLOCK TIGHTENING TORQUE
20 - 17
1
3
2
3
EV100
EV103B
EV103A
5 N.m (3.68 ft-lb)
1 in
50 N.m
(36.88 ft-lb)
8 mm
40 N.m (29.5 ft-lb)
5 mm
10 N.m (7.37 ft-lb)
5 mm
10 N.m
(7.37 ft-lb)
5 mm
10 N.m (7.37 ft-lb)
5 mm
10 N.m
(7.37 ft-lb)
5 N.m
(3.68 ft-lb)
5 N.m
(3.68 ft-lb)
3 mm
5 N.m
(3.68 ft-lb)
3 mm
5 N.m (3.68 ft-lb)
3 mm
5 N.m (3.68 ft-lb)
3 mm
5 N.m
(3.68 ft-lb)
3 mm
5 N.m (3.68 ft-lb)
32 mm
75 N.m (55.32 ft-lb)
32 mm
75 N.m
(55.32 ft-lb)
32 mm
75 N.m (55.32 ft-lb)
3 mm
5 N.m (3.68 ft-lb)
8 mm
40 N.m (29.5 ft-lb)
8 mm
40 N.m (29.5 ft-lb)
8 mm
40 N.m (29.5 ft-lb)
7/8 in
35 N.m
(25.8 ft-lb)
7/8 in
35 N.m
(25.8 ft-lb)
