Manitou MAN'GO 12 Repair Manual

HYDRAULICS
42
70
647534EN
70 - 10/01/2017
80.7
11/16
in
18
±2 N.m
(13±1.48 ft-lb)
270.2
270.1
5 mm
10±0.5 N.m (7±0.37 ft-lb)
320 (Ø0.3 mm (0.11 in))
3 mm
5±0.5 N.m (4±0.37 ft-lb)
80.3
11/16 in
18±2 N.m
(13±1.48 ft-lb)
6 mm
30±1.5 N.m (22±1.11 ft-lb)
245 (Ø0.6 mm (0.02 in)
3 mm
5±0.5 N.m (4±0.37 ft-lb)
80.4
11/16 in
18±2 N.m (13±1.48 ft-lb)
240 (Ø1 mm
(0.039 in))
3 mm
5±0.5 N.m (4±0.37 ft-lb)
6 mm
25±1.5 N.m
(18±1.11 ft-lb)
L3
21 mm
25±1.5 N.m
(18±1.11 ft-lb)
6 mm
30 N.m
(22.13 ft-lb)
80.5
11/16 in
18±2 N.m
(13±1.48 ft-lb)
80.6
11/16 in
18±2 N.m
(13±1.48 ft-lb)
200.1
11/16 in
18±2 N.m
(13±1.48 ft-lb)
70.2
24 mm
42
±2 N.m
(31±1.48 ft-lb)
70.1
24 mm
42±2 N.m
(31±1.48 ft-lb)
100
32 mm
105±6 N.m
(77±4.43 ft-lb)
PB106
27 mm
45±3 N.m (33±2.21 ft-lb)
PB105
27 mm
45±3 N.m (33±2.21 ft-lb)
PB108
22 mm
30±3 N.m
(22±2.21 ft-lb)
200.2
11/16 in
18±2 N.m
(13±1.48 ft-lb)
5 mm
10±0.5 N.m (7±0.37 ft-lb)
90
4 mm
10±0.5 N.m
(7±0.37 ft-lb)
340
8 mm
40±3 N.m (30±2.21 ft-lb)
340
8 mm
40±3 N.m
(30±2.21 ft-lb)
330.2
330.1
80.1
11/16 in
18±2 N.m
(13±1.48 ft-lb)
80.2
11/16 in
18±2 N.m (13±1.48 ft-lb)
