Manitowoc Published 12-05-17, Control # 032-23 3-69
18000 OPERATOR MANUAL OPERATING CONTROLS AND PROCEDURES
3
CAN36-1-64 Swing Left Pressure Sender (7)
CAN36-1-128 Swing Right Pressure Sender (7)
FCN-5-1
Operating Limit Alarm (Beeper) and L.E.D. (1)
CAN36-2-2 Accessory System Hydraulic Pressure Sw. (7)
FCN-5-4
RCL Warning L.E.D. (1)
CAN36-2-4 Swing Brake Solenoid (7)
FCN-5-32
RCL Caution L.E.D. (1)
CAN36-2-8 Swing Lock Out Solenoid (7)
FCN-5-64
RCL Fault Alarm in Cab (1)
CAN36-2-16 Swing Lock In Solenoid (7)
FCN-5-128
System Fault Alarm (Buzzer) and L.E.D. (1)
CAN36-2-32 Travel 2-Speed Solenoid (7)
FCN-6-2
Handle B Display (1)
CAN36-3-4 Travel Brake Solenoid (7)
FCN-6-4
Engine Diagnostics (Red L.E.D.) (1)
CAN36-3-8 Track Auto Lube Solenoid (7)
FCN-6-8
Handle D Display (1)
CAN36-3-16 Swing Bearing Auto Lube Solenoid (7)
FCN-6-16
Handle A Display (1)
CAN37-1-2 CWT Left Cylinder - Retract Solenoid (9)
FCN-6-32
Engine Diagnostics (White L.E.D.) (1)
CAN37-1-4 Counterweight Limit Switch (9)
FCN-6-64
Handle C Display (1)
CAN37-1-8 CWT Right Cylinder - Retract Solenoid (9)
FCN-6-128
Engine Diagnostics (Amber L.E.D.) (1)
CAN37-1-16 CWT Left Cylinder - Extend Solenoid (9)
CAN Packet
Number
Item Description
(Node Number)
CAN Packet
Number
Item Description
(Node Number)
