OPERATING CONTROLS
MODEL 3900W - SERIAL 395143
PUBLICATION DATE TITLE
SECTION 6 - OPERATING CONTROLS
Service Drawing 184679 04/09/97 Standard Hand Signals for Controlling Crane Operations
Folio 1395 12/09/99 Converter Operation Controlled & Non-Controlled Converters
Folio 34-1.1 01/16/84 Swing Lock Control
Folio 34-4.1 03/01/67 Steering Control
Folio 34-5.1 03/01/67 Level
Folio 34-6.16 06/02/81 Instrument Panel
Folio 34-7.1 03/01/67 Selector Valve
Folio 34-11.1 08/01/67 Travel Lock Control
Folio 34-12.1 01/16/84 Manifold Air Pressure Gauge
Folio 34-13.1 10/15/73 Boom Hoist Drum Rotation Indicator
Folio 34-14 03/01/67 Tower Boom Latch Control
Folio 34-15.4 10/15/73 Independent Boom Hoist Auxiliary Brake
Folio 34-16.1 03/01/67 Slide Pinion Control
Folio 34-19.1 09/01/67 Travel Control
Folio 34-20.1 01/16/84 Drum Rotation Indicator
Folio 34-21.1 03/01/67 Independent Swing Control
Folio 34-22.1 03/01/67 Rear Converter Control
Folio 34-24.1 03/01/67 Right Drum Clutch Control
Folio 34-25.8 10/03/85 Independent Boom Hoist Control w/Air Controlled Ratchet & Pawl
Folio 34-26.2 07/01/69 Front Converter Manual Control
Folio 34-27.1 03/01/67 Left Drum Clutch Control
Folio 34-28.1 10/03/85 Engine Hand Throttle
Folio 34-29.2 10/15/73 Air Horn Control
Folio 34-30.1 01/16/84 Left Drum Brake Control-Manual
Folio 34-31.1 01/16/84 Right Drum Brake Control-Manual
Folio 34-32.1 10/03/85 Engine Foot Throttle
Folio 34-33.1 03/01/67 Manual Swing Brake
Folio 34-35.1 01/16/84 Cab Heater Control
Folio 34-36.3 10/30/72 Gantry Lifting Device Control
Folio 34-52.1 01/16/84 Windshield Wiper Control
Folio 34-60.1 09/28/81 Steering Control
Folio 34-60.0 01/16/84 Engine Start-Up and Shut-Down
Folio 34-60.3 10/15/79 Travel Lock Control
Folio 34-60.8 03/01/69 Independent Swing Control
Folio 34-60.11 03/01/69 Travel Control
Folio 34-60.21 10/04/85 Boom Hoist
Folio 34-61.1 03/01/69 Liftcrane
Folio 1315 08/19/03 Preperation for Cold Weather
08/29/05
395143
