SERVICE MANUAL INDEX
MODEL 3900W - SERIAL 395143
PUBLICATION DATE TITLE
SECTION 3 - MAINTENANCE
Folio 445  2-HA-1 Pilotair Valve
Folio 451  2-HA-2 Pilotair Valve
Folio 452  A Pilotair Valve
Folio 503 06/14/96 Shuttle Valve
Folio 525 06/14/96 Air System Deicer
Folio 574 06/10/96 Unloader Pilot Valve Maintenance
Folio 905 07/23/85 Flexair Valves
Folio 1002 06/10/96 Moisture Ejector Valve Maintenance
Folio 1018 03/19/84 Pressure Switch Adjustment
Folio 1019 09/12/79 Pressure Regulating Valve Maintenance
Folio 1037 06/14/96 Air System Filter
Folio 1307 06/14/96 Solenoid Valve
Folio 703 03/04/86 Oil Flow Switch
Folio 1194 04/15/85 Electric Gauges
Folio 933 02/02/78 Boom Hoist Maintenance
Folio 1097 05/03/82 Worm Gear & Worm Shaft Inspection
Folio 932 02/02/78 Drum Brake Maintenance
Folio 1448 07/01/93 Brake Pedal and Latch Inspection
Folio 935 02/03/78 Drum Clutch Maintenance
Folio 188 09/17/84 Engine Cooling Systems
Folio 884 09/12/84 Engine Air Cleaners
Folio 972 04/08/02 Battery Maintenance
Folio 941 08/16/90 Torque Converters
Bulletin Service/Parts Bulletin 10-2 12/12/91 Repair Policy for VICON Controlled Converters
Folio 954 08/17/78 Transmission Case Lubrication System
Folio 981 01/26/79 Oil Filter
Folio 1027 06/25/84 Rotating Bed Sump Circulating Oil System
Folio 1316 10/06/03 Boom, Jib, Tower, and Mast Inspection/Repair
Folio 1354 04/08/02 Boom, Jib, Tower, and Mast Inspection Checklist
Folio 823 04/08/02 Ordering Boom and Jib Lacing
Folio 931 03/31/04 Wire Rope Installation and Maintenance
Folio 997 04/08/02 Load Block and Hook-and-Weight Ball
SECTION 4 - LUBRICATION
Folio 529 03/04/81 Tank & Gear Capacities 4000-4000W Vicon
Folio 424 07/23/96 Lubrication Instructions
Bulletin Service/Parts Bulletin 18-1 04/27/01 Lubricant Specifications
Bulletin Service/Parts Bulletin 18-2 01/08/93 Approved Lubricants for Arctic Operation
SECTION 5 - CAPACITIES
Folio 2081 03/07/05 Capacity Chart Information
Folio 1094 01/27/93 Load Block Data
For lifting capacities, wire rope specifications, drum and lagging information, and
other capacity information, refer to separate capacity chart manual provided with
crane or to laminated capacity charts retained in operator's cab.
SECTION 6 - OPERATING CONTROLS
Service Drawing 184679 04/09/97 Standard Hand Signals for Controlling Crane Operations
Folio 1395 12/09/99 Converter Operation Controlled & Non-Controlled Converters
Folio 34-1.1 01/16/84 Swing Lock Control
Folio 34-4.1 03/01/67 Steering Control
Folio 34-5.1 03/01/67 Level
Folio 34-6.16 06/02/81 Instrument Panel
Folio 34-7.1 03/01/67 Selector Valve
Folio 34-11.1 08/01/67 Travel Lock Control
Folio 34-12.1 01/16/84 Manifold Air Pressure Gauge
Folio 34-13.1 10/15/73 Boom Hoist Drum Rotation Indicator
Folio 34-14 03/01/67 Tower Boom Latch Control
