SET-UP AND INSTALLATION PROCEDURES RT530E-2 OPERATOR’S MANUAL
4-10 Published 5-3-2016, Control # 555-02
.
Detail A
Detail B
3
4
1
9
2
8
6
7
5
Item Description
1 Boom Extension Sheave
2 Boom Extension base
3 Main Boom Base Section
4 Upper Boom Nose Sheaves
5 Lower Boom Nose Sheaves
6 Attach Pins
7 Attach Pins
8Mast Assembly
FIGURE 4-10
Reference Only
