CD5515-2/YB5515-2 OPERATOR MANUAL SPECIFICATIONS
8
SECTION 8
SPECIFICATIONS
SECTION CONTENTS
Lubricants And Capacities . . . . . . . . . . . . . . . . . . 8-1
Engine Oil Specifications . . . . . . . . . . . . . . . . . . . 8-2
Diesel Fuel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3
General Specifications. . . . . . . . . . . . . . . . . . . . . . 8-3
Engine. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3
Electrical System . . . . . . . . . . . . . . . . . . . . . . . . . 8-3
FUEL TANK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3
HYDRAULIC SYSTEM . . . . . . . . . . . . . . . . . . . . . 8-4
Boom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-4
MAST ROTATION - 360°. . . . . . . . . . . . . . . . . . . . 8-4
Wire Rope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-4
Hydraulic System. . . . . . . . . . . . . . . . . . . . . . . . . . 8-4
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-4
Travel Speeds . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5
Operating Dimensions . . . . . . . . . . . . . . . . . . . . . . 8-5
LUBRICANTS AND CAPACITIES
NOTE: The following list of lubricants does not constitute
an unconditional guarantee of the performance of
the lubricant mentioned. It is intended solely as a
guide to the type of lubricant recommended for a
given application.
Component Capacity Lubricant/fluid
Engine crankcase
-Without filter change
-With filter change
9.5 l (10.0 qt)
10.9 l (11.5 qt)
See Engine Manual
Fuel tank 151.4 l (40 gal) See Engine Manual
Cooling system 21.9 l (23 qt) 50/50 Mixture of Glycol Anti-freeze & water.
Hydraulic tank 151.4 l (40 gal)
Mobil Fluid 424 or equivalent (ISO 46/68)
Very Cold Temperatures: SAE 5W or SAE
5W-20 oil if the viscosity will not be less than
60 SUS at maximum operating temperature.
Transmission 2WD
4WD
13.0 l (3.43 gal)
14.0 l (3.70 gal)
Mobil ATF 210 or equivalent
Front axle housing 23.0 l (6.1 gal) Mobil Fluid 424 or equivalent (ISO 46/68)
Front axle wheel hubs (2) 1.5 l (1.65 qt) Mobil Fluid 424 or equivalent (ISO 46/68)
Rear axle housing 18.0 l (4.8 gal) Mobil Fluid 424 or equivalent (ISO 46/68)
Rear axle wheel hubs (2) 1.7 l (1.9 qt) Mobil Fluid 424 or equivalent (ISO 46/68)
Swing gearbox As required
Multipurpose EP Lithium Base grease or
equivalent
Hoist gearbox 1.4-1.9 l (1-1/2-2 qt) SAE 90 EP gear lubricant or equivalent
Hoist brake .2-.5 l (1/2-1 pt) Mobil Fluid 424 or equivalent (ISO 46/68)
Swing gear pinion As required Open gear lube
