Manitowoc Grove YB5515-2 User Manual

GROVE Published 1-20-2017, Control # 468-02 1-3
CD5515-2/YB5515-2 OPERATOR MANUAL INTRODUCTION
1
NOMENCLATURE
1
2
3
5
4
1
6
7
8
9
10
11
12
13
4
14
15
16
17
18
9
FIGURE 1-2
Item Description Item Description
1 Counterweights Location 10 4th Boom Section, 15.2 m (50 ft) (Optional)
2 Main Hoist Location 11 3rd Boom Section, 12.5 m (41 ft) (Standard)
3 Engine Location 12 2nd Boom Section
4 Outriggers (4) 13 1st Boom Section
5 Rear Axle 14 Main Control Valve Location
6 Operator’s Cab 15 Swing Motor and Gearbox Location
7 Front Axle 16 Lift Cylinders (2)
8 Hook Block 17 Crowd Assembly Location (Inside Boom)
9 Anti-Double Blocking System or RCL system 18 Mast
Reference Only
