OPERATING CONTROLS AND PROCEDURES CD5515-2/YB5515-2 OPERATOR MANUAL
3-24 Published 1-20-2017, Control # 468-02
Hoist Rotation Indicator
The hoist rotation indicator is located on the top of the hoist
controller. The indicator is electronically driven by a sensor
attached to the hoist. A pulsating signal is sensed by the
operator’s thumb during hoist operation.
FIGURE 3-36
a0583
a0584
Reference Only
