Part Number 80-1230-9
10/10
79
7.
Disconnect the wate
r supply
.
8.
Reconnect the main power supply to the ice
machine.
9.
Place toggle switch in the clean
position for 30
seconds to drain w
ater from reservoir
, then move
the toggle switch to th
e Off
position.
10.
Disconnect the main power supply to the ice
machine.
!
Warning
Disconnect electri
c power to the ice
machine at
the electric switch box before proceeding.
78
80
