Marantz NR1504 /U1B - REG_SMPS PCB Assy Parts List (cont.)

REG_SMPS
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
C4611 00D9630217002 3300UF-M/16V,12.5*25L.BLK SHL 5.0MC SY D040332083010S 1
C4612,4613 963134502400S MI-0.1UF-J/50V-5RE D020104167050S 2
C4618,4619 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 2
C4620,4621 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 2
C4623 nsp X7R)1UF-K/16V-1608REEL D011105173161S 1
C4629 nsp X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C4632 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 1
C4633-4636 00MOA10601620 10UF-M/16V,3*5-5RE SY D040100083050S 4
C4637 nsp X7R)1UF-K/16V-1608REEL D011105173161S 1
C4639 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 1
C4640,4641 nsp COG470PF-J/50V-1608REEL D010471167160S 2
C4642-4645 nsp X7R0.1UF-K/50V-1608REEL D011104577160S 4
OTHER PARTS GROUP
BKT4141 nsp AVR133(HARMAN) BURRING HOLE SPTE 0.8t/SCREW 4010210196100S 1
BKT4142 nsp AVR3300(E3)(DENON) SPTE 0.8t/SCREW 4010210196000S 1
BKT4601 nsp AVR133(HARMAN) BURRING HOLE SPTE 0.8t/SCREW 4010210196100S 1
BKT4602 nsp AVR3300(E3)(DENON) SPTE 0.8t/SCREW 4010210196000S 1
CLP4606 nsp HMX9800(ON)(HAITAI) (W=2.6,L=50)/WIRE(SOLDER) 4330000120000S 1
CN4141 nsp
370MM/5P TJC2508-5=CKM2509HV-05 WH1007#20 연접
L000371050010S 1
CN4600,4601 nsp C125Z2-09 9P BtoB SOCKET(FEMALE) P=1.25MM L109012520920S 2
CN4606 nsp
120MM/11P 20010HS-11=CKM2002HV-11 WH1007#26 연접
L002121110041S 1
CN4607 nsp
120MM/4P 20010HS-04=CKM2002HV-04 WH1007#26 연접
L002121040110S 1
CP1008 nsp C125Z1-07 7P BtoB HEADER(MALE) P=1.25MM L109012510720S 1
! CP4142 ns
p
LWBP1143-02P 7.92MM HEADER,VER,2CK
T
L108011430210S 1
CP4600,4601 nsp C125Z1-09 9P BtoB HEADER(MALE) P=1.25MM L109012510920S 2
CP4602 nsp 5267-04A 4P L102526700400S 1
CP4603 nsp 5267-03A 3P L102526700300S 1
CP4610,4611 nsp C125Z1-13 13P BtoB HEADER(MALE) P=1.25MM L109012511320S 2
CP4612 nsp C125Z1-07 7P BtoB HEADER(MALE) P=1.25MM L109012510720S 1
CP4613 nsp C125Z1-19 19P BtoB HEADER(MALE) P=1.25MM L109012511920S 1
CP4615 nsp 20010WR-04A00 DIP4P RIGHT ANGLE L101200100420S 1
F4600 963652010500S T1.6A/250V-IVBSUCPCcUR S506 N751501601160S 1
F4600A nsp PI5.2-REEL G645000050010S 1
F4600B nsp PI5.2-REEL G645000050010S 1
F4601 963652010500S T1.6A/250V-IVBSUCPCcUR S506 N751501601160S 1
F4601A nsp PI5.2-REEL G645000050010S 1
F4601B nsp PI5.2-REEL G645000050010S 1
F4602 963652010500S T1.6A/250V-IVBSUCPCcUR S506 N751501601160S 1
F4602A nsp PI5.2-REEL G645000050010S 1
F4602B nsp PI5.2-REEL G645000050010S 1
F4603 963652010500S T1.6A/250V-IVBSUCPCcUR S506 N751501601160S 1
F4603A nsp PI5.2-REEL G645000050010S 1
F4603B nsp PI5.2-REEL G645000050010S 1
J4142-4151 nsp JUMPER (0.6/52MM) L045084006040S 10
J4153 nsp JUMPER (0.6/52MM) L045084006040S 1
J4602,4603 nsp JUMPER (0.6/52MM) L045084006040S 2
J4605 nsp JUMPER (0.6/52MM) L045084006040S 1
J4609-4611 nsp JUMPER (0.6/52MM) L045084006040S 3
J4616-4619 nsp JUMPER (0.6/52MM) L045084006040S 4
J4630 nsp 0-J,1/8W-3216REEL C200000061300S 1
J4631 nsp JUMPER (0.6/52MM) L045084006040S 1
J4634-4638 nsp JUMPER (0.6/52MM) L045084006040S 5
J4640-4650 nsp JUMPER (0.6/52MM) L045084006040S 11
J4653-4661 nsp JUMPER (0.6/52MM) L045084006040S 9
J4663 nsp JUMPER (0.6/52MM) L045084006040S 1
J4670-4687 nsp JUMPER (0.6/52MM) L045084006040S 18
J4689-4693 nsp JUMPER (0.6/52MM) L045084006040S 5
JACK4600 963643012080M DIN-901B(MXJACK) G403901B0000YS 1
JACK4601 963646012090S RCA-206B-02(OR,OR) G601206B0200YS 1
! JK4140 963641011240S
A
C0152PPA66 AC INLET 2P
_
REV1.0 CC
C
G4300152P0001S 1
JP4140,4141 nsp JUMPER (0.6/52MM) L045084006040S 2
JP4601,4602 nsp 0-J,1/8W-3216REEL C200000061300S 2
JP4630 nsp JUMPER (0.6/52MM) L045084006040S 1
! L4140 963111100420D SQ2014 27mH VERTICAL TYPE LINE FILTE
R
U1 D320201405510S 1
! L4140 963111100470S SQ2014 50mH VERTICAL TYPE LINE FILTE
R
N1/K1 D320201405000S 1
! RLY4140 963682100290D JZC-36FD/005-HLT 23.8*9.5*24.5m
m
G680060103030S 1
! T4140 963102100360S EER2834 SW TRANSFORMER GAP BONDING E060283405530S 1
! F4140 963652010510S T2A/250V-IVBSUCPCcUR S50
6
U1 N751502001160S 1
! F4140 963652010500S T1.6A/250V-IVBSUCPCcUR S50
6
N1/K1 N751501601160S 1
F4140_1 nsp PI5.2-REEL G645000050010S 1
F4140_2 nsp PI5.2-REEL G645000050010S 1
! F4141 963652010520S T6.3A/250V-IVBSUCPCcUR S50
6
U1 N751506301160S 1
! F4141 963652010910S T3.15A/250V-IVBSUCPCcUR S50
6
N1/K1 N751503151160S 1
F4141_1 nsp PI5.2-REEL G645000050010S 1
F4141_2 nsp PI5.2-REEL G645000050010S 1
17
