Marantz NR1504 /U1B - SPK_SIDE_CNT PCB Assy Parts List

SPK_SIDE_CNT
SPK
_
SIDE
_
CNT PCB ASS'
Y
※Parts indicated b
y
"ns
p
" on this table cannot be su
pp
lied.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimensions.
NOTE:
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
SEMICONDUCTORS GROUP
D4000-4002 963201500170D LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 3
D4003 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 1
D4004 963201500170D LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 1
D4006 963203500300D DIODE BRIDGE D10SB60 600V/10A STRAIGHT TYPE K047100600220S 1
DZ4000 963202500330D ZJ6.8B-0.5W/5MA-52MM SEMTECH K06006R844522S 1
Q4000 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q4001 943215500020S RT1P141C 0.2W/SC-59 ISAHAYA J520101411210S 1
Q4002 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q4003 943215500020S RT1P141C 0.2W/SC-59 ISAHAYA J520101411210S 1
Q4004 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q4005 943215500020S RT1P141C 0.2W/SC-59 ISAHAYA J520101411210S 1
Q4006 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q4007 943215500020S RT1P141C 0.2W/SC-59 ISAHAYA J520101411210S 1
RESISTOR GROUP
R4000-4004 963125010100S 10-J 2W, R-REEL C060010066050S 5
R4007-4011 963125010100S 10-J 2W, R-REEL C060010066050S 5
R4014 nsp 100-J,1/5W-52RE-AX C00001016P520S 1
R4015 nsp 22-J,1/5W-52RE-AX C00002206P520S 1
R4016,4017 nsp 470-J,1W-R.REEL C060047165050S 2
R4018,4019 nsp 22-J,1/5W-52RE-AX C00002206P520S 2
R4020 nsp 10K-J,1/4W-R.REEL C060103063050S 1
R4022 963125500070D 1.1K-J,1W-R.REEL C060011265050S 1
R4024 963125500070D 1.1K-J,1W-R.REEL C060011265050S 1
R4027 963125500070D 1.1K-J,1W-R.REEL C060011265050S 1
R4028,4029 963129007690M RES CE 0.1-J 5W 14*17 PITCH(10MM) C141R10069010S 2
CAPACIITORS GROUP
C4000-4004 nsp MI-0.047UF-J/50V-5RE D020473167050S 5
C4007 00D2544574922 100UF-M/50V,8*11.5-5RE.SMS SY D040101087060S 1
C4008-4012 nsp MI-0.047UF-J/50V-5RE D020473167050S 5
C4015 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4016-4020 nsp X7R2200PF-K/50V-1608REEL D011222777160S 5
C4030,4031 00D9639003107 6800UF-M/63V DL,30*40-VNSN SY D040682088010S 2
C4033 nsp X7R1000PF-K/50V-1608REEL D011102777160S 1
C4036 nsp X7R1000PF-K/50V-1608REEL D011102777160S 1
C4039 nsp X7R1000PF-K/50V-1608REEL D011102777160S 1
C4042 nsp X7R1000PF-K/50V-1608REEL D011102777160S 1
C4045 nsp X7R1000PF-K/50V-1608REEL D011102777160S 1
C4053 nsp RED-0.1UF-K/250V-5RE PCMT365 D02010407H080S 1
C4054 nsp X7R1000PF-K/50V-1608REEL D011102777160S 1
C4056 00D9630244606 0.1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040R10087080S 1
C4057 nsp RED-0.1UF-K/250V-5RE PCMT365 D02010407H080S 1
OTHER PARTS GROUP
BKT4001,4002 nsp AVR1611BKE3 SECC t1.0+Sn plating /PCB MTG 4010214876000S 2
BKT4005 nsp AVR133(HARMAN) BURRING HOLE SPTE 0.8t/SCREW 4010210196100S 1
CLP4001 nsp HMX9800(ON)(HAITAI) (W=2.6,L=50)/WIRE(SOLDER) 4330000120000S 1
CLP4004,4005 nsp HMX9800(ON)(HAITAI) (W=2.6,L=50)/WIRE(SOLDER) 4330000120000S 2
CLP4007 nsp HMX9800(ON)(HAITAI) (W=2.6,L=50)/WIRE(SOLDER) 4330000120000S 1
CLP4600 nsp HMX9800(ON)(HAITAI) (W=2.6,L=50)/WIRE(SOLDER) 4330000120000S 1
CLP4602 nsp HMX9800(ON)(HAITAI) (W=2.6,L=50)/WIRE(SOLDER) 4330000120000S 1
CLP4604,4605 nsp HMX9800(ON)(HAITAI) (W=2.6,L=50)/WIRE(SOLDER) 4330000120000S 2
CN4000 nsp 230MM/5P 5264-05=CKM2509HV-05 RD1569#20 105C L000231050050S 1
CN4002 nsp 170MM/10P 20010HS-10=CKM2002HV-10 RD1569#26 105C L002171100050S 1
CN4602 nsp C125Z2-13 13P BtoB SOCKET(FEMALE) P=1.25MM L109012521320S 1
CN4603 nsp C125Z2-23 23P BtoB SOCKET(FEMALE) P=1.25MM L109012522320S 1
CN4604 nsp C125Z2-15 15P BtoB SOCKET(FEMALE) P=1.25MM L109012521520S 1
CN4605 nsp C125Z2-19 19P BtoB SOCKET(FEMALE) P=1.25MM L109012521920S 1
CP4000 nsp 20010WS-13A00 DIP13P STRAIGHT L101200101310S 1
CP4001 nsp 35328-0360, 7.92MM HEADER,VER,3CKT L108353280360S 1
CP4604 nsp C125Z1-31 31P BtoB HEADER(MALE) P=1.25MM L109012513120S 1
CP4605 nsp C125Z1-07 7P BtoB HEADER(MALE) P=1.25MM L109012510720S 1
CP4606 nsp C125Z1-25 25P BtoB HEADER(MALE) P=1.25MM L109012512520S 1
CP4614 nsp 20010WR-11A00 DIP11P RIGHT ANGLE L101200101120S 1
J4019-4025 nsp JUMPER (0.6/52MM) L045084006040S 7
J4028-4034 nsp JUMPER (0.6/52MM) L045084006040S 7
J4040-4049 nsp JUMPER (0.6/52MM) L045084006040S 10
J4051-4074 nsp JUMPER (0.6/52MM) L045084006040S 24
J4077 nsp JUMPER (0.6/52MM) L045084006040S 1
J4606 nsp JUMPER (0.6/52MM) L045084006040S 1
J4612-4615 nsp JUMPER (0.6/52MM) L045084006040S 4
J4620-4629 nsp JUMPER (0.6/52MM) L045084006040S 10
J4632,4633 nsp JUMPER (0.6/52MM) L045084006040S 2
J4639 nsp JUMPER (0.6/52MM) L045084006040S 1
J4662 nsp JUMPER (0.6/52MM) L045084006040S 1
J4664-4669 nsp JUMPER (0.6/52MM) L045084006040S 6
J4694,4695 nsp JUMPER (0.6/52MM) L045084006040S 2
J4697,4698 nsp JUMPER (0.6/52MM) L045084006040S 2
JACK4000 963646100530S
JB-601AW-02
(
3RD/3BK 투명
)
G613602AW020YS 1 ＊
JACK4001 963646100550S JB-405EW-02 Stud(Clear) (RD,RD/BK,BK) G612405EW020YS 1 ＊
L4000-4004 nsp SP-2507 1.0 PI*2UEW TURNS=7T SPRING COIL D330900001330S 5
RLY4000-4002 963682100280D JZC-42F/012-2HST 24.4*12.8*24.8mm G680060103010S 3
RLY4004 00D9630218409
BC3-12 24V 2A 2회로 2접점
(
SMALL SIGNAL
)
G680240202030S 1
The symbols in the column "Remarks" indicate the following destinations.
U1 : North America model N1 : Europe model K1 : China model
BK : Black model SG : Silver gold model
