Marantz NR1504 /U1B - Exploded View: Front PCB Assy

EXPLODED
EXPLODED PCB ASS'
Y
※Parts indicated b
y
"ns
p
" on this table cannot be su
pp
lied.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimensions.
NOTE:
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
12 To the HDMI PCB F-HDMI PCB 7028073872010 1 ＊
47 9U6391010600M HDMI PCB ASSY NR1504U U1 7025HK1017065 1 ＊ Ver.3
47 9U6391010700M HDMI PCB ASSY NR1504N N1 7025HK1017075 1 ＊ Ver.3
47 9U6391010800M HDMI PCB ASSY NR1504K K1 7025HK1017095 1 ＊ Ver.3
24 nsp AMP PCB 7028073811010 1 ＊
15 nsp HDMI GUIDE B 7028073897010 1 ＊
16 nsp HDMI GUIDE A 7028073896010 1 ＊
18 nsp GUIDE PCB(L) 7028073893010 1 ＊
38 nsp SPEAKER PCB 7028073891010 1 ＊
42 nsp FCC_GUIDE PCB 7028073895010 1 ＊
46 nsp SIDE_CNT PCB 7028073892010 1 ＊
45 nsp AUDIO_VIDEO PCB U1 7028073851010 1 ＊
45 nsp AUDIO_VIDEO PCB N1 7028073851020 1 ＊
45 nsp AUDIO_VIDEO PCB K1 7028073851030 1 ＊
9 nsp HEADPHONE&SETUP MIC PCB 7028072032050 1 ＊
14 nsp FRONT PCB U1 7028072031050 1 ＊
14 nsp FRONT PCB N1/K1 7028072031060 1 ＊
49 nsp USB PCB 7028072033050 1 ＊
37 nsp SMPS PCB U1 7028073882010 1 ＊
37 nsp SMPS PCB N1/K1 7028073882020 1 ＊
39 nsp REG_CNT PCB 7028073883010 1 ＊
40 nsp REG PCB 7028073881010 1 ＊
43 nsp FRONT_CNT PCB 7028073884010 1 ＊
48 nsp RC-5/M-X 7028073885010 1 ＊
1 963412100780M VOLUME KNOB BK 5080212691000S 2
1 963412100790M VOLUME KNOB SG 5087212691100S 2
2 - NUTS -2
3 963419006180M VOLUME RING BK 5127210901000S 2
3 963419006190M VOLUME RING SG 5127210901100S 2
4 963421006200M BADGE 5630210678000S 1
5 963416100560M WINDOW DISPLAY (ACRYL WINE) 5077212733020S 1
6 963402103640M FRONT PANEL U1 3067215591230S 1 ＊
6 963402103650M FRONT PANEL N1BK 3067215591240S 1 ＊
6 963402103660M FRONT PANEL N1SG 3067215591310S 1 ＊
6 963402103650M FRONT PANEL K1 3067215591240S 1 ＊ Ver.3
7 411510021005M BUTTON POWER Bk 5090213961000S 1 Ver.3
7 943411001970M BUTTON POWER SG 5097213961100S 1
8 963481006080M STANBY LENS 3710210873000S 1
10 963481006070M HDMI LENS 3710210843000S 2
11 963411101820M BUTTON 4KEY BK 5097215011000S 2
11 963411101830M BUTTON 4KEY SG 5097215011100S 2
13 nsp CLAMP 4330210189000S 4
17 nsp HEAT SINK MAIN 2120211838000S 1
19 nsp ACETATE(15*70) 1220210129300S 1
20(Q410) 00D9960018706 MAIN HEAT SINK TR-1 J5011560Y0000S 1
20(Q422) 00D9960018706 MAIN HEAT SINK TR-1 J5011560Y0000S 1
20(Q434) 00D9960018706 MAIN HEAT SINK TR-1 J5011560Y0000S 1
20(Q446) 00D9960018706 MAIN HEAT SINK TR-1 J5011560Y0000S 1
20(Q458) 00D9960018706 MAIN HEAT SINK TR-1 J5011560Y0000S 1
21(Q409) 963219003340S MAIN HEAT SINK TR-2
J502396400010S 1
21(Q421) 963219003340S MAIN HEAT SINK TR-2 J502396400010S 1
21(Q433) 963219003340S MAIN HEAT SINK TR-2 J502396400010S 1
21(Q445) 963219003340S MAIN HEAT SINK TR-2 J502396400010S 1
21(Q457) 963219003340S MAIN HEAT SINK TR-2 J502396400010S 1
22(Q404) 00D9960018706 MAIN HEAT SINK TR-3 J5032390Y0000S 1
22(Q416) 00D9960018706 MAIN HEAT SINK TR-3 J5032390Y0000S 1
22(Q428) 00D9960018706 MAIN HEAT SINK TR-3 J5032390Y0000S 1
22(Q440) 00D9960018706 MAIN HEAT SINK TR-3 J5032390Y0000S 1
22(Q452) 00D9960018706 MAIN HEAT SINK TR-3 J5032390Y0000S 1
23 nsp HEAT SINK BRACKET 4010056906010S 5
25 00M46BW057210 FOOT 4007210321000S 4
26 90M46BW056010 FOOT CUSHION 4050211175000S 4
27 nsp CHASSIS MAIN 3200213586000S 1
28 963403012010M TOP COVER BK 3007211786000S 1
28 963403012020M TOP COVER SG 3007211786010S 1
29 nsp CUSHION SCREW 4050213025000S 4
30 nsp CUSHION TOP 4050214299000S 1
! 31 963101102040M MAIN TRAN
S
U1 8200858630680S 1 ＊
! 31 963101102050M MAIN TRAN
S
N1 8200858630690S 1 ＊
! 31 963101102060M MAIN TRAN
S
K1 8200858630700S 1 ＊
32 nsp SUPPORT 4070210192000S 1
33 nsp MD RUBBER 4050212005000S 1
34 nsp SUPPORT 4070001601010S 1
35 nsp BACK CHASSIS U1 3207214676000S 1
35 nsp BACK CHASSIS N1 3207214676100S 1
35 nsp BACK CHASSIS K1 3207214676110S 1
36 nsp SMPS BRACKET 401021488600DS 1
41 nsp SPACER 4300210062000S 1
44 nsp BUSHING N1/K1 2410040353010S 10
50 nsp USB PLATE 4470212496000S 1
51 nsp RATING SHEET 1210211269000S 1
52 nsp TOOTHED WASHER 1530210216000S 3
53 nsp TOP SHEET 1210211362000S 1
54 - - --
54 - - --
55 - - --
55 - - --
S1 nsp SCREW (+2S 3*10 DOT BK) B020030103B11S 21
S2 nsp SCREW (+2S 3*8 ZNW/BH) B020030081B10S 34
S3 nsp SCREW (+2S 3*17 ZNY/BH) B020030171B10S 1
S4 nsp SCREW (+3S 4*10 ZNY/BH) B028940101B11S 4
S5 nsp SCREW (+2S 3*14 ZNY/HH) B018230141H11S 15
S6 nsp SCREW (+2S 3*8 PI12 WASHER) 1500001456010S 1
S7 nsp SCREW (+2S 3*8 DOT BK/NI) BK B020030083B11S 6
S7 nsp CR601 N1S(MARANTZ) +2S 3*8 B-TYPE(DOT) NI/BH SG B020030084B12S 6
S8 nsp SCREW (+2S 3*10 ZNW/BH) B020030101B10D 15
The symbols in the column "Remarks" indicate the following destinations.
U1 : North America model N1 : Europe model K1 : China model
BK : Black model SG : Silver gold model
