Marantz NR1602 - Connecting Speakers: Bi-Amp Setup; Bi-Amp Connection Diagram; Connection Notes and Impedance

55
FL FR
C
SL
SR
SW
5.1-channel connection
To perform 5.1-channel playback, set “Amp Assign” to “NORMAL” in steps 3 and 4 for “Set up “Amp
Assign”” (vpage59).
NOTE
•For speaker cable connections, see C page 6 “Connecting the speakers”.
•For speaker impedance, see page53.
Connect
Basic version
Advanced version
Information
Advanced version
