About the photos used for "descriptions of the DISASSEMBLY" section
• The shooting direction of each photograph used herein is indicated on the left side of the respective photograph as
"Shooting direction: ***".
• See the diagram below about the shooting direction of each photograph.
• Photographs with no shooting direction indicated were taken from the top of the set.
1. FRONT PANEL ASSY
Proceeding : TOP COVER
→
FRONT PANEL ASSY
(1) Remove the screws and NUT and WASHER.
The viewpoint of each photograph
(Shooting direction X)
［View from the top］
Front side
↓Shooting direction: B↓
Shooting
direction: D
Shooting
direction: C
↑ Shooting direction: A ↑
View from the bottom
NUT and WASHER
11
To Next Page
