Marantz PM8005 - Rear Panel Assy; Main Pcb

5. REAR PANEL ASSY
Proceeding : TOP COVER
→
REAR PANEL ASSY
(1) Cut the wire clamp band, then remove the style pin and screws. Disconnect the connector wires.
6. MAIN PCB
Proceeding : TOP COVER
→
PHONO AMP PCB
→
HEAT SINK ASSY
→
MAIN PCB
(1) Remove the screws.
N8501N7501
N7503
N7502
STYLE PIN
cut
Shooting direction: A
