PRE POWER AMP
PRE POWER AMP PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied.
※The
p
arts listed
b
NOTE:The s
y
mbols in the column Remarks indicate the followin
g
destinations
U : North America model N : Euro
p
e model K : China model F : Ja
p
an mode
B : Black model SG : Silver
g
old mode
l
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D2801-2803 20105001130AS 1SS133(HOMI) 20105001130AS 3
D3001-3005 20105001130AS 1SS133(HOMI) 20105001130AS 5
D3901-3907 20105001130AS 1SS133(HOMI) 20105001130AS 7
D6005-6020 20105001130AS 1SS133(HOMI) 20105001130AS 16
D7003-7006 00MHZ2001499Y
KDS122 TAPIN
G
PM8005N1B : From the serial No.1500 1427 001465
PM8005N1SG : From the serial No.1500 1449 000916
PM8005FN : From the serial No.1500 1446 001001
PM8005U1B : From the serial No.1500 1441 000751
PM
8005
K1B : Fr
o
m
t
h
e
se
ri
a
l N
o
.1
500
1
503
00030
1
00MHZ2001499Y 4 4
! D8001 00D2760706008 FCH20A15 00D2760706008 1
! D8002 00D2760707007 FRH20A15 00D2760707007 1
D8101,8102 00D2760798922 UDZS18B-TE17 00D2760798922 2
D8103,8104 20105001130AS 1SS133(HOMI) 20105001130AS 2
D9011,9012 20105001130AS 1SS133(HOMI) 20105001130AS 2
D9501,9502 20305004130AS 1A7 20305004130AS 2 *
D9503,9504 20105001130AS 1SS133(HOMI) 20105001130AS 2
D9505,9506 20305004130AS 1A7 20305004130AS 2 *
Q2801-2803 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 3
Q3001,3002 21105002140AS KSA992FTA 21105002140AS 2
Q3003-3006 21305002440AS KSC1845FTA 21305002440AS 4
Q3007-3010 21105002140AS KSA992FTA 21105002140AS 4
Q3011-3014 21305002440AS KSC1845FTA 21305002440AS 4
Q3015-3018 21105002140AS KSA992FTA 21105002140AS 4
Q3019-3024 21305002440AS KSC1845FTA 21305002440AS 6
Q3025-3030 21105002140AS KSA992FTA 21105002140AS 6
Q3031,3032 21305002440AS KSC1845FTA 21305002440AS 2
Q3033,3034 21105002140AS KSA992FTA 21105002140AS 2
Q3035,3036 21305002440AS KSC1845FTA 21305002440AS 2
Q3037,3038 21105002140AS KSA992FTA 21105002140AS 2
Q3039-3042 21305002440AS KSC1845FTA 21305002440AS 4
Q3043,3044 21105002140AS KSA992FTA 21105002140AS 2
Q3045 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q3901 00D2730464901 KTC3875S-GR-RTK/P 00D2730464901 1
Q3902 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q6001,6002 21105002140AS KSA992FTA 21105002140AS 2
Q6003-6008 21305002440AS KSC1845FTA 21305002440AS 6
Q6009-6014 21105002140AS KSA992FTA 21105002140AS 6
Q6015,6016 21305002440AS KSC1845FTA 21305002440AS 2
Q6017,6018 21105002140AS KSA992FTA 21105002140AS 2
Q6019,6020 00D2710314903 KTA1024-Y-AT/P 00D2710314903 2
Q6021,6022 00D2730471907 KTC3206-Y-AT/P 00D2730471907 2
Q6023,6024 21305002440AS KSC1845FTA 21305002440AS 2
Q6025-6028 21305001240AS KTC3198-GR-AT/P 21305001240AS 4
Q6029-6034 00D2710300904 KTA1266-GR-AT/P 00D2710300904 6
Q6035,6036 21305001240AS KTC3198-GR-AT/P 21305001240AS 2
! Q7001,7002 00D2730445001 2SC4495 00D2730445001 2
! Q7003,7004 00D2730471907 KTC3206-Y-AT/P 00D2730471907 2
! Q7005,7006 00D2710314903 KTA1024-Y-AT/P 00D2710314903 2
! Q7007,7008 00MHT348832A0 TRANSISTOR 2SC4883 O OR Y 00MHT348832A0 2
! Q7009,7010 00MHT118592A0 TRANSISTOR 2SA1859 O OR Y 00MHT118592A0 2
Q8015 00D2710312905 KTA1504S-GR-RTK/P 00D2710312905 1
! Q8101 00MHT348832A0 TRANSISTOR 2SC4883 O OR Y 00MHT348832A0 1
! Q8102 00MHT118592A0 TRANSISTOR 2SA1859 O OR Y 00MHT118592A0 1
Q8103 00D2710312905 KTA1504S-GR-RTK/P 00D2710312905 1
Q8104 00D2730464901 KTC3875S-GR-RTK/P
00D2730464901 1
Q9001-9004 00D2730464901 KTC3875S-GR-RTK/P 00D2730464901 4
Q9011 00D2710312905 KTA1504S-GR-RTK/P 00D2710312905 1
Q9012 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q9013 00D2690184907 KRA102S-RTK/P (10K-10K) 00D2690184907 1
Q9014-9016 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 3
Q9017 00D2730464901 KTC3875S-GR-RTK/P 00D2730464901 1
Q9018 00D2710312905 KTA1504S-GR-RTK/P 00D2710312905 1
Q9501,9502 00D2710318909 2N5401S-RTK/P 00D2710318909 2
Q9503,9504 00D2730479909 2N5551S-RTK/P 00D2730479909 2
Q9505,9506 00D2710318909 2N5401S-RTK/P 00D2710318909 2
Q9507,9508 00D2730464901 KTC3875S-GR-RTK/P 00D2730464901 2
Q9509 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q9510 00D2730464901 KTC3875S-GR-RTK/P 00D2730464901 1
U3801 23281004150AS NJM8080G 23281004150AS 1 *
U3901,3902 23281004150AS NJM8080G 23281004150AS 2 *
U3903 00MHC10309030 IC LC78212:CMOS LOGIC SANYO 00MHC10309030 1
RESISTOR GROUP
R2801,2802 nsp RD14B2E271JT(5) 00D2412397927 2
R2803,2804 nsp RD14B2E474JT(5) 00D2412404991 2
R2805,2806 nsp RD14B2E271JT(5) 00D2412397927 2
! R2807-2809 00MGG0510016X 10 OHM +- 5% 1/6W 00MGG0510016X 3
R3001,3002 nsp RD14B2E224JT(5) 00D2412404917 2
R3003,3004 nsp RD14B2E221JT(5) 00D2412397901 2
R3005,3006 nsp RD14B2E224JT(5) 00D2412404917 2
R3007,3008 nsp RD14B2E561JT(5) 00D2412397998 2
R3009-3014 nsp RD14B2E224JT(5) 00D2412404917 6
R3015-3020 nsp RD14B2E221JT(5) 00D2412397901 6
R3021,3022 nsp RD14B2E224JT(5) 00D2412404917 2
R3023,3024 nsp RD14B2E273JT(5) 00D2412401994 2
R3025,3026 nsp RD14B2E471JT(5) 00D2412397972 2
R3027-3030 nsp RD14B2E220JT(5) 00D2412394962 4
R3031-3034 nsp RD14B2E153JT(5) 00D2412401936 4
R3035-3038 nsp RD14B2E220JT(5) 00D2412394962 4
R3039,3040 nsp RD14B2E104JT(5) 00D2412403934 2
! R3041,3042 00MGG0510016X 10 OHM +- 5% 1/6W 00MGG0510016X 2
R3043,3044 nsp RD14B2E224JT(5) 00D2412404917 2
R3045,3046 nsp RD14B2E223JT(5) 00D2412401978 2
R3047,3048 nsp RD14B2E471JT(5) 00D2412397972 2
R3049-3052 nsp RD14B2E220JT(5) 00D2412394962 4
