Marantz PM8005 - Page 43

PRE POWER AMP
REF No. Part No. Part Name Remarks Q'ty New Ver
R7029,7030 nsp
RD14B2E152JT(5)
PM8005N1B : From the serial No.1500 1427 001465
PM8005N1SG : From the serial No.1500 1449 000916
PM8005FN : From the serial No.1500 1446 001001
PM8005U1B : From the serial No.1500 1441 000751
PM
8005
K1B : Fr
o
m
t
h
e
se
ri
a
l N
o
.1
500
1
503
00030
1
00D2412398997 2 4
R8001,8002 nsp RD14B2E473JT(5) 00D2412402951 2
! R8003 00MBF68400016 ! 0.68UF/4.7OHM 00MBF68400016 1
! R8021 00MGG0522016X 22 OHM +- 5% 1/6W 00MGG0522016X 1
! R8022 00MGG0510016X 10 OHM +- 5% 1/6W 00MGG0510016X 1
R8023 nsp RM73B--103JT +1608 00D2472009983 1
R8024 nsp RD14B2E103JT(5) 00D2412400995 1
R8025 nsp RM73B--333JT +1608 00D2472011900 1
! R8101,8102 00MGG0504716X 4.7 OHM +- 5% 1/6W 00MGG0504716X 2
R8103,8104 nsp RD14B2E471JT(5) 00D2412397972 2
R8105,8106 nsp RD14B2E102JT(5) 00D2412398955 2
R8107,8108 00MGG0510016X 10 OHM +- 5% 1/6W 00MGG0510016X 2
R8109,8110 nsp RD14B2E333JT(5) 00D2412402919 2
R8111,8112 nsp RD14B2E153JT(5) 00D2412401936 2
R9001 nsp RD14B2E472JT(5) 00D2412400911 1
R9002-9004 nsp RD14B2E103JT(5) 00D2412400995 3
R9011 nsp RM73B--104JT +1608 00D2472012925 1
R9012,9013 nsp RM73B--223JT +1608 00D2472010969 2
R9014 nsp RM73B--472JT (1608) +1608 00D2472009909 1
R9015 nsp RM73B--223JT +1608 00D2472010969 1
R9501,9502 nsp RM73B--154JT +1608 00D2472012967 2
R9503,9504 nsp RM73B--473JT +1608 00D2472011942 2
R9505-9508 00MGG0547116X 470 OHM +- 5% 1/6W 00MGG0547116X 4
R9509,9510 nsp RM73B--154JT +1608 00D2472012967 2
R9511,9512 00MGG0547216X 4.7K OHM +- 5% 1/6W 00MGG0547216X 2
R9513,9514 nsp RM73B--224JT +1608 00D2472013908 2
R9515,9516 nsp RD14B2E682JT(5) 00D2412400953 2
R9517-9522 nsp RD14B2E223JT(5) 00D2412401978 6
R9523,9524 nsp RD14B2E683JT(5) 00D2412402993 2
R9525 nsp RM73B--104JT +1608 00D2472012925 1
CAPACIITORS GROUP
C3000 nsp CK73F1E104ZT +1608 00D2570512903 1
C3005-3008 nsp CK73F1E104ZT +1608 00D2570512903 4
C3017 nsp CK73F1E104ZT +1608 00D2570512903 1
C3021,3022 00MOA106035Z1 ROS-35V 100M - F3#PE - T2 (10UF 35V) 00MOA106035Z1 2
C3023,3024 00MOF55331581 330PF 100V +- 10% FNS 00MOF55331581 2
C3025,3026 00MOA226025Z1 ROS-25V 220M - F3#PE - T2 (22UF 25V) 00MOA226025Z1 2
C3027,3028 00MOA227025R1 ROA-25V 221M -H5#PE - T2 (220UF 25V) 00MOA227025R1 2
C3029,3030 00MOA106035Z1 ROS-35V 100M - F3#PE - T2 (10UF 35V) 00MOA106035Z1 2
C3031,3032 00MOF55331581 330PF 100V +- 10% FNS 00MOF55331581 2
C3033,3034 00MOA226025Z1 ROS-25V 220M - F3#PE - T2 (22UF 25V) 00MOA226025Z1 2
C3035,3036 00MOA227025R1 ROA-25V 221M -H5#PE - T2 (220UF 25V) 00MOA227025R1 2
C3037,3038 00MOA226025Z1 ROS-25V 220M - F3#PE - T2 (22UF 25V) 00MOA226025Z1 2
C3041,3042 00MOF55101591 100PF 200V +- 10% FAS 00MOF55101591 2
C3043-3046 00MOA227025R1 ROA-25V 221M -H5#PE - T2 (220UF 25V) 00MOA227025R1 4
C3047,3048 00MOF55101591 100PF 200V +- 10% FAS 00MOF55101591 2
C3049,3050 00MOA226025Z1 ROS-25V 220M - F3#PE - T2 (22UF 25V) 00MOA226025Z1 2
C3801,3802 00MOA476025R1 ROA-25V 470M -G3# - T2 00MOA476025R1 2
C3803-3806 00MOA106035Z1 ROS-35V 100M - F3#PE - T2 (10UF 35V) 00MOA106035Z1 4
C3901,3902 00MOA476025R1 ROA-25V 470M -G3# - T2 00MOA476025R1 2
C3903,3904 13405014840AS CE04W1J100MT(KR3) 13405014840AS 2
C3907,3908 13405014840AS CE04W1J100MT(KR3) 13405014840AS 2
C3909 133050086503S CQ93M2A221JT(PEF) 133050086503S 1
C3910-3912 13405014840AS CE04W1J100MT(KR3) 13405014840AS 3
C3916 00MOA10605021 10 UF M 50V RA-2 00MOA10605021 1
C6001,6002 00MOA226025Z1 ROS-25V 220M - F3#PE - T2 (22UF 25V) 00MOA226025Z1 2
C6003,6004 00MOF55101591 100PF 200V +- 10% FAS N/K 00MOF55101591 2
C6005-6008 00MOA22706326 220 UF M 63V RA-2 00MOA22706326 4
C6009-6012 00MOA476025Z1 ROS-25V 470M - G3#PE - T2 (47UF 25V) 00MOA476025Z1 4
C6013,6014 00MOF55681581 680PF 100V +-10% FNS 00MOF55681581 2
C6015,6016 00MOA22702521 220 UF M 25V RA-2 00MOA22702521 2
C7001,7002 00MOA106035Z1 ROS-35V 100M - F3#PE - T2 (10UF 35V) 00MOA106035Z1 2
C7003,7004 00MOF55103581 0.01UF 100V +- 5% FNS 00MOF55103581 2
! C8001,8002 13405024500AM LKG1J183MESJZT
13405024500AM 2 *
C8021 00MOA22706326 220 UF M 63V RA-2 00MOA22706326 1
C8022 00MOA106035Z1 ROS-35V 100M - F3#PE - T2 (10UF 35V) 00MOA106035Z1 1
C8101-8104 00MOA227025R1 ROA-25V 221M -H5#PE - T2 (220UF 25V) 00MOA227025R1 4
C8105,8106 00MOA106035Z1 ROS-35V 100M - F3#PE - T2 (10UF 35V) 00MOA106035Z1 2
C9001 00D2544573949 CE04W1H010MT(RA3) 00D2544573949 1
C9002 00MOA10605021 10 UF M 50V RA-2 00MOA10605021 1
C9003 nsp CK73F1E104ZT +1608 00D2570512903 1
C9011-9016 nsp CK73F1E104ZT +1608 00D2570512903 6
C9501,9502 nsp CK73B1H103KT (1608) +1608 00D2570501901 2
C9503-9506 00D2544573949 CE04W1H010MT(RA3) 00D2544573949 4
C9507 00D2544577945 CE04W1C101MT(RA3) 00D2544577945 1
OTHER PARTS GROUP
B3901 nsp 5P L=130 SCN-SCN UL1430 UL2791 61301004100AS 1 *
B6001,6002 nsp EHR-SCN 2.5MMPICH DIP TYPE 5PIN 8CM 120105920040 2
B8001 nsp SIN-SRA 1P 140MM 120500040000 1
B9501 nsp EHR-SCN 2.5MMPICH DIP TYPE 4PIN 10CM 120106080080 1
K3001 643810029001S RCA PIN JACK 2P AU MSP-242V3-12 GILT LF 643810029001S 1
K3002,3003 643810028008S RCA PIN JACK 4P AU MSP-244V4-17 GILT LF 643810028008S 2
K3004 643810029001S RCA PIN JACK 2P AU MSP-242V3-12 GILT LF 643810029001S 1
L9102 nsp MLB-1608-1000A-N2 00MFC9002021Y 1
N2801 nsp B5B-EH-TS (LF)(SN) 5P RADIAL TAPING 00MYP0601045X 1
N2802 nsp B3B-EH-TS (LF)(SN) 3P RADIAL TAPING 00MYP0600383X 1
N2803 nsp B6B-EH-TS (LF)(SN) 6P RADIAL TAPING JST 00MYP0600384X 1
N3301 nsp B5B-EH-TS (LF)(SN) 5P RADIAL TAPING 00MYP0601045X 1
N5001 nsp 13P PLUG(C125Z1) 645010056014S 1
N7001,7002 nsp B5B-EH-TS (LF)(SN) 5P RADIAL TAPING 00MYP0601045X 2
N7003-7006 nsp 6P PIN HEADDER 2.54MM PITCH ANGLE 64401018300AS 4
N7007,7008 nsp S2B-EH 00MYP06003920 2
N7009 nsp 4P-PLUG B4P-VH 00MYP06003890 1
N8001 nsp JST 3P-PLUG B3P-VH P=3.96M/M 00MYP06006860 1
N8101 nsp B3B-EH-TS (LF)(SN) 3P RADIAL TAPING 00MYP0600383X 1
N9001 nsp B13B-PH-K-S (LF)(SN) 00MYJ06006330 1
N9002 nsp B4B-EH-TS (LF)(SN) 4P RADIAL TAPING 00MYP0600391X 1
S2801-2804 00D2140208003 RELAY(NA24W-K) 00D2140208003 4
