The
Command (Output)
This command is used to print information on the calibration:
1 Select the command with the arrow keys, and press
PRINT .
The output is sent to an attached printer or PC.
2 Press the MENU key to return to the Setup Mode.
3 Press the MENU key a second time to return to Operating
Mode.
The following is an example of a printout from the
command:
M1100: U2-3.10 / CAL=2 / CON=2
App: 1000 0000 0000 0000
Cap: 15.000 kg
Res: Single
CS: 5 kg
C0: 601495
C2: 840888
Gain: 2.088615e-05 kg/cnt
g-adj: 1.00000
Set: 0000 0000 0000 1000
aP: 10.0
aZ: 5.0
aY: 0
aX: 0
bP: 10.0
bZ: 5.0
bY: 0
bX: 0
The
Command (CAN ID)
Use this command to view and set the CAN identification number if the
M1100 scale is (to be) connected to other equipment via a CAN
connection:
1 Select the command with the arrow keys, and press
PRINT to display the current ID on the Weight Display.
2 Press PRINT again. The first digit to the right on the
display starts to flash, indicating that it can be changed to a
new value.
3 Use the UP/DOWN arrows to change the value for the ID
number. Press
PRINT to activate each digit.
Note: You must activate all digits (press PRINT six
times) or no change will take place.
4 Press the MENU key to return to Setup Mode.
5 Press the MENU key a second time to return to Operating
Mode.
36 • Advanced functions M1100, U2 & C2-3.3
