6A-15POWER TRIM90-13645--2 495
Battery Voltage Indicated:
D Check “Up” solenoid terminals for loose or
corroded connections.
D Check BLACK ground wire (on “Up” sole-
noid) for corrosion or open.
D Test “Up” solenoid. Refer to “Motor and
Electrical Tests/Repair,” following.
Troubleshooting the “Up” Circuit*
(When “Down” Circuit Is OK)
* Remote Control NOT Equipped with Trailer Button
Connect Voltmeter RED lead to Point 10
and BLACK lead to ground.
Depress the “Up” trim button.
No Voltage Indicated:
Trim Switch is faulty or there is an open
circuit in wires [GREEN-WHITE,
BLUE-WHITE and PURPLE-WHITE (or
PURPLE)] between trim point 7 and trim
pump.
D Check trim switch.
D Check all trim harness connectors for
loose or corroded connections.
D Check for pinched or severed wires.
Battery Voltage Indicated:
D Connect Voltmeter RED lead to Point 6.
D Depress “Up” trim button.
Battery Voltage Indicated:
Connect Voltmeter RED lead to Point 3.
No Voltage Indicated:
D Check for loose or corroded connec-
tion at Point 9 or Point 3.
D Check RED lead between Point 9 and
Point 3 for open.
No Voltage Indicated:
Solenoid is defective.
To Next Page
