53D0419 45
REPLACEMENT PARTS ARE AVAILABLE THROUGH YOUR RETAILER
REPLACEMENT PARTS
DESIGNER
Item Description Qty Natural Propane
1 Left Bottom Log (#1) 1 42D0401 42D0401
2 Right Bottom Log (#2) 1 42D0400 42D0400
3 Bottom Center Log (#3) 1 42D0403 42D0403
4 Bottom Front Log (#4) 1 42D0402 42D0402
5 Left Log Top (#5) 1 42D0404 42D0404
6 Top Log (#6) 1 42D0405 42D0405
Fireplace
7 Junction Box 1 26D2128K 26D2128K
8 Large Glass Assembly
(Peninsula, See-Through) 1* 42D0364K 42D0364K
8 Large Glass Assembly
(Corner Left, Corner Right) 1* 42D0366K 42D0366K
9 Small Glass Assembly
(Peninsula) 1 42D0365K 42D0365K
9 Small Glass Assembly
(Corner Left, Corner Right) 1 42D0406K 42D0406K
10 Small Floor Firebrick 1 42D0163 42D0163
11 Large Floor Firebrick 1 42D0164 42D0164
12 Small Wall Firebrick 1 42D0165 42D0165
13 Large Wall Firebrick 1 42D0166 42D0166
Engine Assembly
14 Wire Harness Male 1 44D0501 44D0501
15 Sit 820 Nova Valve 1 37D0117 37D0118
16 Knob Extension Hi/Lo 1 43D0095 43D0095
17 Knob Extension On/Off 1 43D0094 43D0094
18 Pilot Assembly 1 37D0018K 37D0019K
19 Burner Assembly 1 42D0500 42D0501
20 Burner Injector 1 42D0502 42D0503
21 Flexhose With Shutoff Valve 1 23D6046K 23D6046K
22 Rocker Switch 1 41D0048 41D0048
23 Wire Harness Female 1 44D0500 44D0500
Accessories (Not Shown)
Thermostatic Remote Control 1 RCT RCT
Remote Control On/Off 1 RCM RCM
Wall Switch Kit 1 MVWS MVWS
Wall Thermostat Kit 1 MVWTS MVWTS
Available Not Shown
Deflector Shield 1 37D0115K 37D0115K
Propane Gas Conversion Kit 1 6000CKN —
Natural Gas Conversion Kit 1 — 6000CKP
Failure to position the
parts in accordance
with these diagrams
or failure to use only
parts specifically
approved with this
appliance may result
in property damage or
personal injury.
WARNING
