Martin MAC Aura User Manual

Onboard control menus 29
Onboard control menus
Menu Item Options Notes (Default settings in bold print)
DMX ADDRESS 1 – XXX
DMX address (default address = 1). The DMX address
range is limited so that the fixture will always have
enough DMX channels within the 512 available.
CONTROL
MODE
STD
Linked control of Beam and Aura using Beam channels,
Aura copies Beam
(fixture uses 14 DMX channels)
EXT
Independent control of Beam and Aura, FX available
(fixture uses 25 DMX channels)
COLOR CALIB
ON
Color calibration mode on. Independent white control not
available for Beam on DMX channel 13 (white obtained
by RGB dimming)
OFF
Color calibration mode off. White available for Beam
on DMX channel 13 to give raw RGBW dimming
PERSONALITY
P/T SETTING
P/T SPEED Pan and tilt speed normal / fast / slow
SWAP
Swap pan and tilt (pan commands move tilt and vice
versa) - off / on
PAN INVERT Pan inversion (reverse direction pan control) - off / on
TILT INVERT Tilt inversion (reverse direction tilt control) - off / on
FANS
REGULATED Cooling fan speed thermostatically regulated
FULL Max. cooling fan speed
DIMMER
CURVE
LINEAR Linear dimming curve
SQUARE LAW Square law dimming curve
INV SQUARE
LAW
Inverse square law dimming curve
S-CURVE S-curve dimming curve
DIMMER
SPEED
FAST Fast dimming with unrestricted speed
SMOOTH Smooth dimming with restricted speed
DMX RESET
OFF Disable reset via DMX
ON Enable reset via DMX
DISPLAY
ON Display is always on
2MIN
Display switches off and goes into Sleep mode if the
controls have not been pressed for 2 minutes.
5MIN
Display switches off and goes into Sleep mode if the
controls have not been pressed for 5 minutes
10MIN
Display switches off and goes into Sleep mode if the
controls have not been pressed for 10 minutes
DISPLAY
INTENSITY
10-100 Display intensity. Default=100
ERROR MODE
NORMAL
Display errors at 100% intensity (regardless of
DISPLAY INTENSITY setting) and illuminate the
service light
SILENT
Silent error mode. The error message does not appear in
the display, but the service lamp is illuminated
FACTORY
SETTING
FACTORY
DEFAULT
LOAD
Return all settings (except calibrations) to factory
defaults
NB: can take up to 2 minutes to complete!
Table 4: Control menu

Martin MAC Aura Specifications

General

Light Source	RGBW LED
Control Protocol	DMX, RDM
Pan Movement	540°
Power Consumption	200 W
Light Output	3850 lumens
Input Voltage	100-240 V AC, 50/60 Hz
Zoom Range	11° - 58°
Weight	5.6 kg
Width	302 mm
