Martin MAC Aura User Manual

22 MAC Aura user manual
DMX protocol
Channel
DMX
value Percent Function
Fade
status
Default
value
Std. Ext.
1
0 - 19
20 - 24
25 - 64
65 - 69
70 - 84
85 - 89
90 - 104
105 - 109
110 - 124
125 - 129
130 - 144
145 - 149
150 - 164
165 - 169
170 - 184
185 - 189
190 - 204
205 - 209
210 - 224
225 - 229
230 - 244
245 - 255
0 - 7
8 - 9
10 - 25
26 - 27
28 - 33
34 - 35
36 - 41
42 - 43
44 - 49
50 - 51
52 - 57
58 - 59
60 - 65
66 - 67
68 - 73
74 - 75
76 - 81
82 - 83
84 - 89
90 - 91
92 - 97
98 - 100
Beam electronic shutter effect
Shutter closed
Shutter open
Strobe 1 (fast → slow)
Shutter open
Strobe 2: opening pulse (fast → slow)
Shutter open
Strobe 3: closing pulse (fast → slow)
Shutter open
Strobe 4: random strobe (fast → slow)
Shutter open
Strobe 5: random opening pulse (fast → slow)
Shutter open
Strobe 6: random closing pulse (fast → slow)
Shutter open
Strobe 7: burst pulse (fast → slow)
Shutter open
Strobe 8: random burst pulse (fast → slow)
Shutter open
Strobe 9: sine wave (fast → slow)
Shutter open
Strobe 10: burst (fast → slow)
Shutter open
Snap 22
2
0 - 255 0 - 100
Beam dimmer
0 → 100% intensity
Fade 0
3
0 - 255 0 - 100
Zoom
Wide → narrow
Fade 255
4
0 - 255 0 - 100
Pan
Left → right
Fade 128
5
0 - 255 0 - 100
Pan fine
Pan fine adjustment (Least Significant Byte)
Fade 32768
6
0 - 255 0 - 100
Tilt
Tilt 0 - 232°
Fade 128
7
0 - 255 0 - 100
Tilt fine
Tilt fine adjustment (Least Significant Byte)
Fade 32768
Table 2: MAC Aura DMX Protocol

Martin MAC Aura Specifications

General

Light Source	RGBW LED
Control Protocol	DMX, RDM
Pan Movement	540°
Power Consumption	200 W
Light Output	3850 lumens
Input Voltage	100-240 V AC, 50/60 Hz
Zoom Range	11° - 58°
Weight	5.6 kg
Width	302 mm
