Martin MAC Aura User Manual

DMX protocol 23
8
0 - 9
10 - 14
15 - 39
40 - 44
45 - 49
50 - 54
55 - 59
60 - 64
65 - 69
70 - 74
75 - 89
90 - 94
95 - 99
100 - 104
105 - 109
110 - 114
115 - 119
120 - 124
125 - 249
250 - 255
0 - 3
4 - 5
6 - 13
14 - 15
16 - 17
18 - 19
20 - 21
22 - 23
24 - 25
26 - 27
28 - 33
34 - 35
36 - 37
38 - 40
41 - 42
43 - 44
45 - 46
47 - 48
49 - 97
98 - 100
Fixture control settings
No function
Reset entire fixture
1
No function
PTSP = NORM
2
PTSP = FAST
2
PTSP = SLOW
2
No function
Fan mode FULL
2
No function
Fan mode REGULATED
2
No function
Calibrated color output mode COLOR CALIB = ON
3
No function
Raw color output mode COLOR CALIB = OFF
3
No function
Fast dimming, speed of changes unrestricted
2
No function
Smooth dimming, speed of changes restricted slightly
2
No function
Illuminate display
1
If DMX Reset is disabled in the menu, a reset command can
only be executed if channel 2 is set to 232 and channel 1 is set
to zero. These values need to be held for 5 seconds before
feature is activated. Values must be "snapped to" to function.
2
Menu override: setting unaffected by power off/on.
3
Value must be held for 3 seconds to activate. Setting
unaffected by power off/on.
Snap 0
Channel
DMX
value Percent Function
Fade
status
Default
value Std. Ext.
Table 2: MAC Aura DMX Protocol

Martin MAC Aura Specifications

General

Light Source	RGBW LED
Control Protocol	DMX, RDM
Pan Movement	540°
Power Consumption	200 W
Light Output	3850 lumens
Input Voltage	100-240 V AC, 50/60 Hz
Zoom Range	11° - 58°
Weight	5.6 kg
Width	302 mm
