Martin MAC III User Manual

MAC III Wash DMX protocol 41
8
0
1 - 19
20
21 - 39
40
41 - 59
60
61 - 79
80
81 - 99
100
101 - 119
120
121 - 139
140
141 - 159
160
161 - 164
165 - 168
169 - 172
173 - 176
177 - 180
181 - 184
185 - 188
189 - 192
193 - 214
215 - 221
222 - 243
244 - 247
248 - 251
252 - 255
0
1 - 7
8
9 - 15
16
17 - 23
24
25 - 31
32
33 - 39
40
41 - 47
48
49 - 55
56
57 - 63
64
65 - 66
67 - 68
69 - 70
71 - 72
73 - 74
75 - 76
77 - 78
79 - 80
81 - 86
87 - 88
89 - 94
95 - 96
97 - 98
99 - 100
Color Wheel
Continuous Scroll
Open
Open → Slot 1 - Blue
Slot 1
Slot 1 → Slot 2 - Green
Slot 2
Slot 2 → Slot 3 - Orange
Slot 3
Slot 3 → Slot 4 - Minus green
Slot 4
Slot 4 → Slot 5 - Yellow
Slot 5
Slot 5 → Slot 6 - Deep blue (Congo)
Slot 6
Slot 6 → Slot 7 - Red
Slot 7
Slot 7 → Open
Open
Stepped Scroll (snap to full color positions)
Slot 7 - Red
Slot 6 - Deep blue (Congo)
Slot 5 - Yellow
Slot 4 - Minus green
Slot 3 - Orange
Slot 2 - Green
Slot 1 - Blue
Open
Continuous Rotation
CW, Fast → Slow
Stop (This will stop wherever the wheel is at the time)
CCW, Slow → Fast
Random color
Fast
Medium
Slow
Snap 0
9
0 - 18
19 - 57
58 - 83
84 - 109
110 - 135
136 - 255
0 - 6
7 - 22
23 - 32
33 - 42
43 - 52
53 - 100
Color shake/ random CMY
No function (Note: use DMX value 005 - 010 when setting calibration values
on channel 21)
Color wheel: fast narrow shake → slow wide shake, around currently
selected color
Random CMY: set min./ max. CMY range limits on channels 4 - 6
Fast
Medium
Slow
No function
Snap 0
10
0 - 199
200 - 215
216 - 229
230 - 243
244 - 249
250 - 255
0 - 77
78 - 84
85 - 89
90 - 94
95 - 97
98 - 100
Iris
Open → closed
Closed
Opening pulse, fast → slow
Closing pulse, fast → slow
Random opening pulse, fast → slow
Random closing pulse, fast → slow
Fade 0
11
0 - 255 0 - 100
Internal barndoor 1
Out → in
Fade 0
12
0 - 255 0 - 100
Internal barndoor 2
Out → in
Fade 0
13
0 - 22
23
24 - 230
231
232 - 255
0 - 9
9
9 - 90
90
91 - 100
Internal barndoors rotation
-10° → -1°
0° (vertical)
+1° → +89°
+90° (horizontal)
+91° → +100°
Fade 23
DMX
channel
DMX
value
Percent Function
Fade
type
Default
value
Table 2: MAC III Wash DMX Protocol
