Masibus LC5248E-AT User Manual

Model: LC5296-AT /LC5248E-AT/LC5296V-AT masibus
Doc. Ref. no. : - m61C/om/301
Issue no. 13
User’s Manual Page 16 of 44
%Power.
SET-1
Key/ SET-
2 Key
(Menu /
Enter
Key)
 For Linear Output, Shows Alarm Set Point-1(A1.SP), if
pressed one time in RUN mode.
 For Other Output Type, shows Control Set Point-1(C1.SP),
if pressed in RUN mode.
 In Sub Menu it can be used to get to the next Parameter.
 It is also used to save the parameters to nonvolatile
memory, when user setting a proper data by Increment
and decrement key for parameter configuration.
 Shows Alarm Set Point-2(A2.SP), if pressed two times in
RUN mode. Shows Sok.t(Run/stop) if pressed three times
in RUN mode.
Auto/Man
ual Key
 It is used to switch between Auto to Manual mode and
Manual to Auto mode if pressed for at least 2 sec if
function key is A/M.
 Shows remaining soak time when pressed if function key is
selected SOK.T.
PV
(Process
Value)
Display
PV
 4 digital 0.40 inch RED Display(for LC5248E-AT)
 4 digital 0.36 inch RED Display(for LC5296V-AT)
 Display process value.
 Display parameter name when user set parameter
 Display error message when an error occurs.
SV
(Set
Value)
Display
SV
 4 digital 0.28 inch GREEN Display(for LC5248E-AT)
 4 digital 0.31 inch GREEN Display(for LC5296V-AT)
 Display set value.
 Display parameter value of parameter in process value
field when user set parameter.
 Display control output value when in manual mode.
Relay-1
Indication
RL1
 ON when Relay-1 is energized & OFF otherwise.
Relay-2
Indication
RL2
 ON when Relay-2 is energized & OFF otherwise.
SSR
Indication
SSR
 SSR ON status.
MANUAL
Indication
MAN
 ON when unit is in Manual mode.
 OFF when unit in Auto Mode.
TX
Indication
Tx
 ON when device is transmitting some Data (RS-485).
RX
Indication
Rx
 ON when device is receiving some Data (RS-485).
